Fiber Laser Cutting Machine / Laser Cutting Machine - Linkweld Industries Model PipeMaster 6000 AUTOLOAD - Pipe cutting 6000 watt
The Fiber Laser Cutting Machine / Laser Cutting Machine - Linkweld Industries - PipeMaster 6000 AUTOLOAD - Pipe cutting 6000 watt is designed for automated production (Auto Loading), reducing labor, increasing speed, and raising the standard of metal cutting in industrial factories.
With a 6000W Fiber Laser, it can cut steel, stainless steel, and aluminum pipes quickly, sharply, smoothly, and with high precision, ideal for mass production.
▶︎ Key Features of Fiber Laser Cutting Machine / Laser Cutting Machine - Linkweld Industries Model PipeMaster 6000 AUTOLOAD - Pipe cutting 6000 watt
🔹 6000W laser power for fast cutting and heavy-duty work.
🔹 Auto Load system for automatic pipe feeding, reducing time and labor.
🔹 Supports pipes up to Ø 240 mm and lengths up to 7000 mm.
🔹 BOCI SHARP cutting head provides sharp, smooth cuts, reducing post-production work.
🔹 Raycus laser source is stable and has a long service life.
🔹 TUBEPRO software is easy to use and supports CNC applications.
🔹 Pneumatic clamping system reduces vibration and increases accuracy.
🔹 Inspection camera + alarm system. Enhanced safety during operation.
▶︎ Specifications of Fiber Laser Cutting Machine / Laser Cutting Machine - Linkweld Industries Model PipeMaster 6000 AUTOLOAD - Pipe cutting 6000 watt
| 🔹 Cutting Type: | PIPE (Steel Pipe / Stainless Steel / Aluminum) |
| 🔹 Laser Power: | 6000 W |
| 🔹 Laser Source: | Raycus (GE Global Warranty) |
| 🔹 Laser Head: | BOCI BLT 421 FL150 Sharp Head |
| 🔹 Control System: | 3000DEG-G |
| 🔹 Software: | TUBEPRO |
▶︎ Supported Workpiece Sizes
| 🔹 Round Pipe: | Ø 20–240 mm |
| 🔹 Square Tube: | ≤ 240 mm |
| 🔹 H-BEAM: | Minimum–Maximum Height 15–150 mm |
| 🔹 Maximum Pipe Length: | 7000 mm |
| 🔹 Minimum Tail: | 0 mm when pipe length ≥ 800 mm |
▶︎ Clamping and Drive System
| 🔹 Clamping System: | Pneumatic |
| 🔹 Follow-up/Down Function: | Features include |
| 🔹 Rack Gear: | YYC |
| 🔹 Guide Rail: | PEK |
| 🔹 X, Y, Z Drive System: | INVT |
| 🔹 Reducer: | SHIMPO |
▶︎ Electrical Systems and Accessories
| 🔹 Breaker & Relay: | CHNT |
| 🔹 Electrical Parts: | CHNT |
| 🔹 Proportional Valves O₂: | ✓ |
| 🔹 Air Conditioner: | ✓ |
| 🔹 Exhaust Blower: | ✓ |
| 🔹 Voltage Stabilizer: | ✓ |
| 🔹 Water Chiller: | TONGFEI / S&A / HANLI |
| 🔹 UPS for Computer: | ✓ |
| 🔹 WIFI Adapter: | ✓ |
| 🔹 Abnormal Alarm Light: | ✓ |
▶︎ Graphic File Support
🔹 IGS, ZX, ZZX
▶︎ Monitoring & Security Systems Front Panel Status Lights (LED GREEN / YELLOW / RED)
🔹 2 CCTV Cameras with Computer Connectivity
▶︎ Additional Features
🔹 Supports pipes up to 240 mm
🔹 Precise clamping system reduces pipe end vibration.
🔹 BOCI SHARP cutting head, sharp and suitable for heavy-duty factory use.
🔹 TUBEPRO software is easy to use and focuses on stability.
🔹 Sharp and fast cutting with 6000W power from Raycus.
