Fiber Laser Welding Machine / Laser Welding Machine – Linkweld Industries Model 30W
The Fiber Laser Welding Machine / Laser Welding Machine – Linkweld Industries Model 30W is a non-contact laser marking machine that delivers permanent, high-precision marks. It is suitable for a wide range of materials including metals, plastics, and ceramics. With its ultra-fine laser beam, this marking machine can achieve sharp and detailed results that traditional methods cannot match.
▶︎ Key Features of Fiber Laser Welding Machine / Laser Welding Machine – Linkweld Industries Model 30W
🔹 New modern design
🔹 Supports Thai text marking
🔹 Fast and smooth marking performance
🔹 Easy to use, full set with software
▶︎ Technical Specifications of Fiber Laser Welding Machine / Laser Welding Machine – Linkweld Industries Model 30W
| Item | Description |
|---|---|
| Model Name | Fiber Laser Marking Machine 30W (Marking Area 150×150 mm) |
| Laser Source | MAXPHOTONICS |
| Laser Power | 30W |
| Laser Wavelength | 1064 nm |
| Frequency Range | 10–400 KHz |
| Pulse Width Range | 200 ns |
| Marking Speed | ≤ 7000 mm/s |
| Minimum Line Width | ≤ 0.02 mm |
| Minimum Character Size | 0.05 mm |
| Repeat Accuracy | ±0.001 mm |
| Marking Area | 150 × 150 mm |
| Cooling Method | Air Cooling |
| Working Voltage | 220V / 50Hz / 3A |
| Marking Software | JCZ Laser Marking Software |
| Focus Adjustment | Motorized Height Adjustment System |
| Display Monitor | 22” FHD Screen |
| Control Computer | High-performance Core i5 (Fast marking, stable operation) |
