Fiber Laser Welding X’Treme – Elite
Fiber Laser Welding Machine – X’TREME ELITE (4-in-1 Function)
A professional-grade welding system that combines 4 functions in one machine:
Welding / Cutting / Rust Cleaning / Seam Cleaning
Technical Parameters
- Laser: Maxphotonic
- Welding Head: DWT22
- Water Chiller: 13L
Optical Characteristics
- Output Power: 1500W / 2000W
- Operating Mode: Continuous / Pulse
- Working Hours: 24 hours per day
- Welding Materials: Stainless steel, carbon steel, and other metals
- Welding Thickness: 0.5 – 6.0 mm (depending on material)
- Welding Speed: 50 – 800 mm/min
Operating Environment
- Ambient temperature 10–35°C
- Relative humidity 30–85%
- Power supply: 220V / 5%, 50Hz
Other Parameters
- Machine Dimensions: 875 × 590 × 870 mm
- Wire Feeder Dimensions: 200 × 150 × 185 mm
- Output Mode: Standard QBH
Supported Material Thickness
| Material | Thickness |
|---|---|
| Carbon Steel | 4 / 5 / 6 mm |
| Stainless Steel | 4 / 5 / 6 mm |
| Aluminum | 2 / 3 / 4 mm |
| Galvanized Sheet | 1.5 / 2 / 3 mm |
Standard Set
- MAX Laser Source
- S&A Chiller (13L)
- Laser safety goggles
- Full nozzle set (0.8–1.6 mm)
- 10-meter welding cable
Key Features
- Touch screen interface (Thai language)
- Touch screen wire-feed controller
