VICTOR Plasma Cutting CUTMASTER 35

VICTOR Thermal Dynamics Cutmaster 35 manual plasma is a high duty cycle, inverter based system specifically designed for heavy duty applications requiring superior cutting performance. The unit is specifically designed to serve the 35 mm market with a high duty cycle of 80% in a 40°C ambient environment. Operating from a 415V three phase supply, the design incorporates features such as auto-pilot re-start, True Guard roll bar and the heavy duty SL100™ 1Torch® for superior performance. The unit can also be used for heavy duty gouging applications when fitted with the correct torch consumables.
These features combined with a three year limited warranty make this the ideal unit for and heavy duty fabrication, construction and mining applications.

Features:

• Front Panel LED’s indicate status conditions for maximum efficiency
• Trigger latch feature prevents hand fatigue during long cuts. Auto pilot restart instantly re-ignited the pilot arc while cutting expanded metals
• True Guard roll bar provides easy transportation and protection for excellent durability
• Tip Saver current fold back circuit design prevents tip failure when the tip touches the work piece at high output current levels resulting in prolonged consumable parts life
• Storage compartment for convenient access to spare parts and consumables
• Versatile 1Torch with ATC disconnect makes it easy to add lead extensions offering a combined extension lead length of up to 30.5m

Specifications:

• Supply Voltage: 415 Volt, 3 phase, 50/60Hz 400 V, 27 A, 50/60 Hz
• Maximum Output Range: 100 amps
• Duty Cycle: 80% @ 100A %
• Weight: 28.1 kg
• Dimensions (mm): 381H x 305W x 762L mm
